Pedrollo UPm 8/2 240V 1.5HP High Flow Submersible Pump w/ Float
The UP.240V.1P.1.5HP.HP is a high-performance horizontal cistern pump designed for efficient water transfer in residential and light commercial applications. Operating at 230V single-phase, this 1.5 HP pump delivers robust flow rates, making it ideal for systems requiring consistent water pressure.
Choose Quantity :
Product Information
Product Details
Key Specifications
- Model: UP.240V.1P.1.5HP.HP
- Power Supply: 230V, Single-phase
- Motor Power: 1.5 HP
- Current Draw: 7.7 Amps
- Maximum Flow Rate: 32 GPM @ 50 PSIG
- Shutoff Pressure: 100 PSID
- Minimum Submergence: 3 inches
- Discharge Outlet: 1¼" FPT
- Dry Weight: 31 lbs (14 kg)
- Orientation: Horizontal
Standard Inclusions
- Horizontal cistern pump unit
- 1¼" FPT discharge connection
- User manual
Applications Suitable for:
- Cistern water transfer
- Rainwater harvesting systems
- Residential water supply
- Light commercial water systems
Certifications & Compliance
- Manufactured by Georgia Water Tanks
- Compliant with industry standards for cistern pumps
Shipping & Handling
- Shipping Dimensions: Not specified
- Shipping Weight: Approximately 31 lbs (14 kg)
- Packaging: Securely boxed with protective materials
- Delivery: Standard ground shipping
