Bulkhead Fitting 1" Slip
This 1-inch PVC bulkhead fitting is designed for secure and leak-proof connections in tank and reservoir applications. Featuring socket x socket end connections and an EPDM flange gasket, it ensures a reliable seal for various fluid handling systems.
Product Details
🔍Key Specifications
Part Number: BFA1010SES
Size: 1 inch
Material: PVC
Gasket: EPDM flange gasket
End Connections: Socket x Socket
Maximum Pressure: 150 psi
Temperature Range: 40°F to 140°F (4°C to 60°C)
Color: Gray
Standards: NSF/ANSI 61 and NSF/ANSI 372 listed
🛠️Standard Inclusions
1" PVC bulkhead fitting
EPDM standard flange gasket
Locknut for tank installation
🛠️ Applications Suitable for:
Water storage tanks
Aquariums
Rainwater harvesting
Irrigation systems
Industrial fluid containment
📄 Certifications & Compliance
NSF/ANSI 61 certified for potable water use
NSF/ANSI 372 certified for lead-free compliance
Meets U.S. plumbing code standards
🚚 Shipping & Handling Notes
Shipping Dimensions: 3" L × 3" W × 3" H
Shipping Weight: 0.5 lbs
Packaging: Individually boxed with protective padding
Delivery: Standard ground shipping
