Digital Pressure Monitor, -15 to 145 PSI, 4-20 mA Loop
The PS500-8010N14MA3-EN is a robust digital pressure monitor engineered for industrial automation, process control, and fluid systems. It provides highly accurate monitoring over a vacuum-to-positive pressure range, with a loop-powered 4-20 mA analog output for seamless integration into SCADA and PLC systems. Its compact, panel-mountable design with bright digital display makes it ideal for real-time pressure readouts in demanding environments.
Digital Pressure Monitor -15-0-145 4-20 mA loop powered output and setpoint switch. Displays pressure in PSI. With 1/4" MPT 316 stainless piping connection and 10' lead
Product Details
📏 Key Specifications
Model Number: PS500-8010N14MA3-EN
Pressure Range: -15 to 0 to +145 PSI (vacuum through positive gauge pressure)
Output: 4-20 mA, loop-powered (2-wire)
Power Supply: 12-36 VDC (loop powered)
Accuracy: Typically ±0.5% FS
Display: Digital LED / LCD (depending on build variant)
Process Connection: 1/4" NPT (standard)
Enclosure: Compact rugged enclosure with front display
Operating Temp: -4°F to 158°F (-20°C to 70°C)
Ingress Protection: IP65 (typical, confirm model specifics)
Approvals: CE compliant; industry standard EMC
🚚 Shipping & Handling
Packaging: Individually boxed with documentation
Shipping Weight: ~1.5 lbs
Shipping Method: Standard parcel service (UPS/FedEx)
Delivery Time: Typically 2-4 weeks (verify at quote)
Installation Notes: Wiring requires 2-wire 4-20 mA loop with external power supply
