Snyder Industries 12000 Gallon Water Tank - PN - 32076
Heavy-duty polyethylene tank ideal for potable water, rainwater harvesting, or fire protection storage
──────────────────────────────────────────────────────────────────────────
Product Overview
The Snyder Industries 12000 Gallon Vertical Water Storage Tank is a durable and safe solution for long-term above-ground water storage. Constructed from FDA-approved, food-grade high-density polyethylene (HDPE) using a rotational molding process, this tank features a seamless, leak-proof design. Its UV-stabilized exterior reduces sunlight exposure, inhibiting algae growth, making it ideal for rainwater collection, well water storage, and emergency backup supply.
Snyder 12000 Gallon Plastic Water Storage Tank
Constructed with durable, rotationally molded polyethylene resin, ensuring resistance to cracks, chips, and ruptures.
Built with materials that meet FDA standards for safe-food grade storage, ensuring compliance and safety.
Equipped with UV inhibitors to protect liquid contents from direct sunlight, suitable for indoor and outdoor use.
The black or dark green color prevents light penetration, reducing the growth of algae in the water.
The tanks come pre-fitted with a heavy-duty, bolted bottom drain fitting and a top fitting located near the manway for tank float accessories.
Tanks come standard with large manway openings for easy cleaning and inspection.
📱 For freight quote and lead time.
| Technical Documents | |
|---|---|
| View Technical Drawing | |
| NSF Certification | |
| FDA Statement | |
| Warranty Statement | |
Out of stock
Product Information
Product Details
Key Specifications
• Capacity: 12000 gallons
• Dimensions: 142" Diameter x 196.5" Height
• Weight: 2075 lbs
• Material: High-Density Polyethylene (HDPE)
• Color Options: Black or Green (UV-stabilized)
• Specific Gravity: 1.0 (for potable water)
• Max Temp: 120°F
• Manway: 26" Threaded Vented
• Inlet: 1.5" FNPT Bulkhead Fitting
• Outlet: 2" FNPT Bolted Bulkhead Fitting
• Gallon Indicators: Molded-in
• Certifications: FDA CFR 177.1520, NSF/ANSI 61
───────────────────────────────────────────────────────────────────────────
Shipping & Handling
• Shipping Dimensions: 142" Diameter × 196.5" Height
• Shipping Weight: 2075 lbs
• Freight Class: 400
• Truckload Quantity: 2 tanks
• Overdimensional: Yes
• Liftgate: Not available
• Ships From: Merced, California
| Dimensions | |
|---|---|
| Diameter | 142" |
| Length | 142" |
| Width | 142" |
| Height | 196.5" |
| Weight | 2075lbs |
| Inlet | 1.5 |
| Outlet | 2 |
| Lid Size | 26" |
| Key Specs | |
|---|---|
| Manufacturer | Snyder Industries |
| Color | Black |
| Gallon Capacity | 12000 |
| Gallon Indicators | 1 |
| Specific Gravity | 1 |
| Material | High Density Linear Polyethylene |
| Max Temperature | 120 F/ 48 C |
| Certifications & Compliances | ANSI / NSF 61 Approved, FDA Approved |
| Warranty | 3 years |
