Rain Harvesting WDIG10 In-Ground First Flush Diverter
🌧️ Rain Harvesting WDIG10 In-Ground First Flush Diverter
Part Number: WDIG10
💧 High-Capacity In-Ground Diverter to Improve Rainwater Quality and Convert System from Wet to Dry
The Rain Harvesting WDIG10 In-Ground First Flush Diverter is engineered to improve the quality of collected rainwater by isolating and discarding the initial, most contaminated runoff. Designed for in-ground installation, this diverter effectively transforms a "wet" system—where water remains in pipes after rainfall—into a "dry" system by ensuring complete drainage between rain events. This not only prevents anaerobic fermentation but also reduces maintenance and extends the lifespan of pumps and appliances connected to your rainwater harvesting system. :contentReference[oaicite:0]{index=0}
$299.95
$345.95
Choose Quantity :
Product Information
Product Details
- 📄 Key Specifications • Model: WDIG10 • Diversion Capacity: Customizable based on pipe length (e.g., each meter of 300mm pipe diverts approximately 72 liters) • Material: Durable, UV-stabilized PVC • Installation: Requires a minimum 5% slope (1:20) for effective drainage • Compatibility: Suitable for systems with 3", 4", or 12" PVC pipes • Application: Ideal for residential and commercial rainwater harvesting systems ───────────────────────────────────────────────────────────────────────✅ Benefits • Improves water quality by diverting the first flush of contaminated runoff • Converts "wet" systems to "dry," preventing stagnant water and associated issues • Reduces maintenance by preventing sediment buildup in tanks and pipes • Enhances the longevity of pumps and appliances by supplying cleaner water • Customizable diversion volume to suit specific roof areas and pollution levels • In-ground installation keeps the system discreet and space-efficient ───────────────────────────────────────────────────────────────────────🔧 Installation Overview 1. Determine the appropriate location for installation, ensuring a minimum 5% slope for drainage. 2. Connect the diverter to your downpipe system using compatible PVC fittings. 3. Customize the length of the diversion chamber based on your roof area and pollution levels. 4. Install the slow-release valve to allow gradual drainage of the diverted water. 5. Ensure all connections are secure and test the system to confirm proper operation. ───────────────────────────────────────────────────────────────────────🚚 Shipping & Handling • Shipping Dimensions: 20" L × 20" W × 20" H • Shipping Weight: 2 lbs • Ships From: United States • Shipping Method: Standard ground shipping
📄 Key Specifications
• Model: WDIG10
• Diversion Capacity: Customizable based on pipe length (e.g., each meter of 300mm pipe diverts approximately 72 liters)
• Material: Durable, UV-stabilized PVC
• Installation: Requires a minimum 5% slope (1:20) for effective drainage
• Compatibility: Suitable for systems with 3", 4", or 12" PVC pipes
• Application: Ideal for residential and commercial rainwater harvesting systems
───────────────────────────────────────────────────────────────────────
✅ Benefits
• Improves water quality by diverting the first flush of contaminated runoff
• Converts "wet" systems to "dry," preventing stagnant water and associated issues
• Reduces maintenance by preventing sediment buildup in tanks and pipes
• Enhances the longevity of pumps and appliances by supplying cleaner water
• Customizable diversion volume to suit specific roof areas and pollution levels
• In-ground installation keeps the system discreet and space-efficient
───────────────────────────────────────────────────────────────────────
🔧 Installation Overview
1. Determine the appropriate location for installation, ensuring a minimum 5% slope for drainage.
2. Connect the diverter to your downpipe system using compatible PVC fittings.
3. Customize the length of the diversion chamber based on your roof area and pollution levels.
4. Install the slow-release valve to allow gradual drainage of the diverted water.
5. Ensure all connections are secure and test the system to confirm proper operation.
───────────────────────────────────────────────────────────────────────
🚚 Shipping & Handling
• Shipping Dimensions: 20" L × 20" W × 20" H
• Shipping Weight: 2 lbs
• Ships From: United States
• Shipping Method: Standard ground shipping
