CorGal WST3302 – 46,500 Gallon Steel Water Tank
💧 High-Capacity, Wide-Diameter Water Tank for Stormwater, Irrigation & Fire Protection
🛠️ Product Overview
The WST3302 is a low-profile, heavy-duty corrugated steel water tank engineered for reliable above-ground storage in commercial, agricultural, and municipal applications. With a wide 33′ diameter, it provides a 46,500-gallon capacity and is ideal for stormwater retention, irrigation systems, or emergency fire reserves. Built to support over 392,000 lbs when full, it combines durable galvanized construction with efficient site assembly.
Product Details
📏 Key Specifications
Model: WST3302
Capacity: 46,500 gallons
Diameter: 33′ 0″
Eave Height: 7′ 3″
Peak Height: 16′ 3″
Full Weight When Loaded: ~392,000 lbs
Material: Corrugated galvanized steel panels
Applications: Stormwater storage, irrigation, fire protection, rainwater harvesting
Installation: Above-ground, with optional dome roof or open-top configurations
🚚 Shipping & Handling
Packaging: Flat-packed corrugated steel panels
Shipping Method: Freight
Delivery Time: 6–8 weeks from order
Installation Time: 4–6 days with certified crew
Site Prep: Compacted gravel base or concrete ring beam
Tools Required: Forklift or crane for unloading
