SBS Tank ST19R09 – 327.6K Gal, 100 MPH, NFPA 22 & Seismic Z2B
🛠️ Product Overview
The SBS Tank ST19R09 is a heavy-duty, high-volume bolted steel reservoir built for extreme environmental resilience. Engineered to meet 100 MPH wind load standards and Seismic Zone 2B compliance, this tank is ideal for municipal, industrial, and fire suppression systems requiring long-term, high-capacity storage. Its modular design with Galvalume® construction ensures rapid installation and unmatched durability in demanding conditions.
📞Contact Us for freight quote and lead time (Typical delivery time: 12–16 weeks)
Product Brochure:
Tank Sizing Chart:
Product Details
📏 Key Specifications
Capacity: 327,570 gallons (gross), 309,000 gallons (usable)
Model Number: ST19R09
Diameter: 42′ 7″
Height: 30′ 10″
Wall Panels: Galvalume® steel, G300/G550 grade with AZ150 coating
Roof: Self-supporting corrugated dome roof
Liner: NSF/ANSI 61-certified synthetic liner
Wind Rating: Up to 100 MPH
Seismic Rating: Zone 2B compliant
Tank Color: Mill-finish (silver); optional powder-coated exterior
Bolt Design: M10/M12 hot-dip galvanized high-tensile bolts
Nozzles: 2″–6″ galvanized steel or optional HDPE/stainless steel
Lifespan: 60+ years under normal operating conditions
Warranty: 12-month materials/workmanship + 20-year no-leak conditional warranty
📦 Shipping & Handling
Packaging: Flat-packed steel panels and liner
Shipping Weight: ~16,000–17,500 lbs (estimated)
Shipping Method: Containerized freight
Delivery Time: 10–12 weeks (from receipt of order & deposit)
Installation Time: ~6–9 days with certified crew
Site Prep: Level pad with compacted sand or concrete ring beam
Installation Requirements: Forklift or crane required for unloading
