CorGal WST4203-NR – 112,900 Gallon Open-Top Steel Water Tank
🛠️ Product Overview
The WST4203-NR offers 112,900 gallons nominal and 101,900 gallons of usable capacity, purpose-built with no roof for applications requiring direct top access. At 42′ diameter and 10′ 9″ high, this open-top corrugated steel tank supports bulk storage for agriculture, environmental systems, or temporary staging where roofless tanks are required.
Product Details
📏 Key Specifications
Model: WST4203-NR
Nominal Capacity: 112,900 gallons
Usable Capacity: 101,900 gallons
Height: 10′ 9″
Diameter: 42′ 0″
Full Load Weight: ~860,000 lbs
Roof: None (Open Top)
Material: Corrugated galvanized steel
Applications:
Environmental containment
Temporary frac or detention storage
Rainwater collection
Agricultural or livestock use
🚚 Shipping & Handling
Packaging: Flat-packed kit for on-site assembly
Shipping Method: LTL or flatbed freight
Lead Time: 6–8 weeks typical
Installation Time: 1–3 days depending on crew
Foundation Required: Compacted gravel, concrete ring beam, or pad
