CorGal WST2104-WT-CHR – 36,000 Gallon Steel Tank Kit
🛠️ Product Overview
The CorGal WST2104-WT-CHR is a high-performance corrugated steel water storage tank kit designed for non-potable applications such as irrigation, stormwater retention, and industrial reuse. Featuring a 30° corrugated high-rib roof and a 22 oz. reinforced PVC liner, this tank offers long-lasting structural integrity and reliable containment. The kit includes everything needed for standard field assembly and is backed by a 30-year limited structural warranty.
Product Details
📏 Key Specifications
Model: WST2104-WT-CHR
Nominal Capacity: 36,000 gallons
Diameter: 21′
Eave Height: 14.33′
Peak Height: 20.5′
Roof Style: 30° corrugated high rib
Liner: 22 oz. non-potable reinforced PVC
Structure Material: Corrugated galvanized steel
Warranty:
30-year limited structural warranty
10-year pro-rated liner warranty
🚚 Shipping & Handling
Packaging: Flat-packed for optimized freight
Delivery Time: Varies by region – standard lead time 6–8 weeks
Installation Time: ~5–7 days with certified crew
Site Prep: Requires compacted base or concrete ring beam
Installation Requirements: Forklift or crane recommended for unloading
