CorGal WST3602F – 55,300 Gallon Flat-Roof Steel Water Tank
🛠️ Product Overview
The WST3602F is a 55,300-gallon corrugated galvanized steel tank designed with a 36′ diameter and a flat 7′3″ roof profile. Engineered for efficient high-volume storage with easy roof access, this tank is ideal for stormwater management, industrial operations, and fire suppression systems. With a full load weight exceeding 466,000 lbs, it offers excellent structural strength and is built for rapid assembly on prepared sites.
Product Details
📏 Key Specifications
Model: WST3602F
Capacity: 55,300 gallons
Diameter: 36′ 0″
Roof Style: Flat
Roof Height: 7′ 3″
Full Load Weight: ~466,000 lbs
Material: Corrugated galvanized steel panels
Applications:
Stormwater retention
Fire reserve tank
Industrial or agricultural water storage
Design: Above-ground with flat-roof profile for simplified vertical clearance and access
🚚 Shipping & Handling
Packaging: Flat-packed galvanized steel tank components
Shipping Method: Freight
Lead Time: 6–8 weeks standard
Installation Time: 4–6 days with certified crew
Site Prep: Compacted sand pad or reinforced concrete ring beam
Tools Required: Forklift or crane for unloading
