CorGal 1503-WT-CHR – 14,000 Gallon Steel Water Tank Kit
💧 Compact CorGal Steel Tank Kit for Irrigation, Stormwater & Utility Storage
🛠️ Product Overview
The CorGal Model 1503-WT-CHR is a 14,000-gallon corrugated galvanized steel water tank kit built for strength, versatility, and performance in non-potable storage applications. Engineered for wind speeds up to 115 MPH and seismic conditions (Design Category C), this tank features a 30° galvanized roof with inspection hatch, reinforced PVC liner, and low-profile venting. Ideal for stormwater capture, irrigation systems, and utility use, it offers reliable, long-term containment in a compact footprint.
Product Details
📏 Key Specifications
Model: 1503-WT-CHR
Nominal Capacity: 14,000 gallons
Diameter: 15′
Eave Height: 10.75′
Peak Height: 15.17′
Roof Style: 30° galvanized roof assembly with inspection hatch
Wall Panels: Corrugated galvanized steel
Wind Rating: 115 MPH
Roof Load Rating: 20 psf live load
Seismic Design: Category C
Ventilation: Low-profile roof vent – 49 in² open area
Anchoring: Reinforced anchors (final specs per SDCP)
Liner: 22 oz non-potable reinforced PVC
Warranty:
30-year limited structural warranty
10-year pro-rated liner warranty
🚚 Shipping & Handling
Packaging: Flat-packed for efficient transport
Shipping Destination: Freight to Georgia
Lead Time: 6–8 weeks standard
Installation Time: 3–5 days with certified crew
Site Requirements: Level base with compacted sand or concrete ring beam
Installation Tools: Forklift or crane recommended
