Pioneer Water Tanks KIT-XLE30/02-ZN – 39,707 Gallons
Full Kit Pack Pioneer Water Storage Tank, 39,707 Gallons, Zincalume Silver, 30 ft. 9 in. D x 7 ft. 2 in. H, Includes Tank Body, Aqualiner Fresh with Geotex Underlay, Lockable Access Latch and Removable Ladder, 6 in. PVC Overflow, Sacrificial Anodes, and Roof System Tank model XLE 30/02 will yield 34,218 net usable gallons when equipped for fire protection.
STANDARD INCLUSIONS
AQUALINER® FRESH
The first antimicrobial tank liner in the world, our exclusive five-layer AQUALINER® Fresh keeps your water fresher for longer with embedded Sanitized® Silver technology. With a life expectancy of 65 years, the AQUALINER® Fresh is designed to fit the Pioneer Water Tank to prevent contamination.
GEOTEXTILE UNDERLAY
Our geotextile underlay is the ideal way to protect your AQUALINER® Fresh from being compromised by sharp objects that may be caught inside your water tank.
SUPER SEAL
Reduce the number of contaminants to protect your precious water supply with Pioneer Water Tanks’ high-density foam sealer.
SACRIFICIAL ANODES
Our sacrificial magnesium anodes significantly extend the life of your water tank by protecting the tank from corrosion. Made from magnesium, the anodes erode in place of the water tank, thereby protecting the steel and allowing the tank to last longer than other systems. Pioneer Water Tanks recommend your anodes be replaced every 10 years so you can enjoy the benefits of your tank for life.
6-INCH DIAMETER OVERFLOW
Pioneer Water Tanks provides a 6” diameter overflow downpipe, the largest overflow system on the market. The overflow size moves excess water away from the tank quickly to effectively reduce pressure on your tank and avoid costly damage to your tank components.
$26,112.00
Choose Quantity :
Product Information
Product Details
📄 Key Specifications
Model: KIT-XLE30/02-ZN
Nominal Capacity: 39,707 Gallons
Net Usable (Fire Protection): 34,218 Gallons
Diameter: 30′ 9″
Height: 7′ 2″
Material: Zincalume® Steel Panels
Liner: AQUALINER® Fresh with Geotex Underlay
Overflow: 6″ PVC Overflow Pipe
Outlet: Configurable (not specified in base kit)
Access: Lockable access latch and removable ladder
Extras: Sacrificial anodes and complete roof system included
🌿 Features
• Full tank kit including structure, liner, roof, access, and fittings
• AQUALINER® Fresh inhibits bacterial growth and protects water quality
• Durable Zincalume® construction with corrosion resistance
• Ready for residential, agricultural, or fire system integration
• Modular assembly for fast field setup
🔧 Applications
• Rainwater harvesting and potable water storage
• Agricultural and irrigation systems
• Fire reserve water (NFPA-compliant setups possible)
• Rural and commercial infrastructure
🚚 Shipping & Handling
Ships via freight in labeled skid packaging
Includes all components: tank body, roof, liner, ladder, fittings
Shipping weight: ~3,000–3,500 lbs
Assembly instructions and component guide included
