SBS ST08R07 Water Tank – 45.2K Gallons, 100 MPH Wind Rated
💧 Compact Cyclonic‑Rated Steel Water Tank for Fire Protection & Storage
🛠️ Product Overview
The SBS Tank ST07R07 is a high-performance bolted steel water reservoir engineered for fire protection and potable water storage in compact spaces. Designed for durability in high-wind zones, it features a modular Galvalume® steel body, NSF/ANSI 61-certified liner, and a self-supporting dome roof. This tank is fully NFPA 22-compliant, corrosion-resistant, and easily transported for fast on-site assembly.
📞Contact Us for freight quote and lead time (Typical delivery time: 12–16 weeks)
Product Brochure:
Tank Sizing Chart:
Product Details
📏 Key Specifications
Capacity: 45,214 gallons (gross), 39,900 gallons (usable)
Model Number: ST08R07
Diameter: 17′ 11″
Height: 24′
Wall Panels: Galvalume® steel, G300 grade with AZ150 coating
Roof: Self-supporting corrugated dome roof
Liner: NSF/ANSI 61-certified synthetic liner
Wind Rating: Up to 100 MPH
Seismic Rating: Earthquake zone compatible
Tank Color: Mill-finish (silver); optional powder-coated exterior
Bolt Design: M10/M12 hot-dip galvanized high-tensile bolts
Nozzles: 2″–6″ galvanized steel or optional HDPE/stainless steel
Lifespan: 60+ years under normal operating conditions
Warranty: 12-month materials/workmanship + 20-year no-leak conditional warranty
📦 Shipping & Handling
Packaging: Flat-packed steel panels and liner
Shipping Weight: ~7,000–8,000 lbs (estimated)
Shipping Method: Containerized freight
Delivery Time: 10–12 weeks (from receipt of order & deposit)
Installation Time: ~3–5 days with certified crew
Site Prep: Level pad with compacted sand or concrete ring beam
Installation Requirements: Forklift or crane required for unloading
