CorGal WST4203 – 112,900 Gallon Steel Water Tank
🛠️ Product Overview
The WST4203 is a 112,900-gallon nominal capacity corrugated steel tank engineered for robust above-ground water storage. With a 42′ diameter and 23′ peak roof, it’s ideal for commercial, agricultural, and light industrial applications where reliability and volume matter. Usable water capacity is 101,900 gallons, supporting critical storage needs.
Product Details
📏 Key Specifications
Model: WST4203
Nominal Capacity: 112,900 gallons
Usable Capacity: 101,900 gallons
Diameter: 42′ 0″
Peak Roof Height: 23′ 1″
Eave Height: 10′ 9″
Full Load Weight: ~860,000 lbs
Material: Corrugated galvanized steel
Applications:
Agricultural irrigation
Fire protection reserves
Industrial water systems
Rainwater harvesting
🚚 Shipping & Handling
Packaging: Shipped in flat-packed kit form
Shipping Method: LTL/Flatbed Freight
Lead Time: 6–8 weeks
Installation Time: 2–4 days with trained crew
Foundation Required: Engineered ring beam or concrete pad
