Contain Water System 4806 – Steel Water Tank
💧 Ultra‑high‑capacity corrugated galvanized steel water tank engineered for municipalities, industrial facilities, irrigation, and large‑scale fire protection
🛠️ Product Overview
The Contain Water Systems 4806 Steel Water Tank is a premier mega‑capacity reservoir designed to store over 1 million gallons of water. Built from heavy‑duty corrugated galvanized steel panels and equipped with an NSF/ANSI 61 certified potable liner, this tank is engineered for maximum strength, durability, and compliance with NFPA‑22 and AWWA standards. Its modular bolted design ensures efficient shipping, professional on‑site assembly, and a service life of 60+ years, making it an ideal choice for municipalities, fire protection reserves, and large‑volume industrial or agricultural water needs.
📞 Contact us for freight quote and lead time
Fire Protection
Warranty
Product Details
📏 Key Specifications
Capacity: ~1,000,000 gallons (configuration dependent)
Model Number: 4806
Diameter: ~48 ft
Height: ~27 ft (6‑ring wall system; varies with roof type)
Roof Options: 30° V‑rib or flat seam galvanized steel
Material: Corrugated G115 galvanized steel panels
Liner System: NSF/ANSI 61 certified potable PVC liner with geotextile pre‑liner
Certifications: NSF/ANSI 61 potable, NFPA‑22 & AWWA compliant
Warranty: 20‑year prorated structural warranty; 10‑year liner warranty
Applications: Municipal potable water storage, industrial process water, fire suppression reserves, irrigation, and stormwater harvesting
🚚 Shipping & Handling
Packaging: Flat‑packed corrugated steel panels, roof trusses, liner, and hardware
Shipping Method: Containerized or full truckload freight; crane or forklift required for unloading
Shipping Weight: ~40,000+ lbs depending on configuration
Delivery Time: Typically 16–20 weeks
Installation: On‑site assembly by certified crew; requires an engineered concrete ring beam or reinforced pad foundation
