SBS Tank ST14R02 – 40.5K Gal, 100 MPH Wind Rated, NFPA 22 & Seismic Compliant
🛠️ Product Overview
The SBS Tank ST14R02 is a wide-diameter, low-height engineered reservoir designed for high-capacity water storage in seismic and cyclonic regions. Constructed with Galvalume® steel panels and equipped with seismic design calculations and NFPA 22 compliance, this tank is ideal for municipalities and facilities requiring stable, fast-deploying fire protection or potable storage.
Product Brochure:
Tank Sizing Chart:
Product Details
📏 Key Specifications
Capacity: 40,490 gallons (gross), 35,000 gallons (usable)
Model Number: ST14R02
Diameter: 31′ 4″
Height: 7′
Wall Panels: Galvalume® steel, G300 grade with AZ150 coating
Roof: Self-supporting corrugated dome roof
Liner: NSF/ANSI 61-certified synthetic liner
Wind Rating: Up to 100 MPH
Seismic Rating: Seismic design package included
Tank Color: Mill-finish (silver); optional powder-coated exterior
Bolt Design: M10/M12 hot-dip galvanized high-tensile bolts
Nozzles: 2″–6″ galvanized steel or optional HDPE/stainless steel
Lifespan: 60+ years under normal operating conditions
Warranty: 12-month materials/workmanship + 20-year no-leak conditional warranty
📦 Shipping & Handling
Packaging: Flat-packed steel panels and liner
Shipping Weight: ~7,000–8,500 lbs (estimated)
Shipping Method: Containerized freight
Delivery Time: 12–14 weeks (from receipt of order & deposit)
Installation Time: ~4–6 days with certified crew
Site Prep: Level pad with compacted sand or concrete ring beam
Installation Requirements: Forklift or crane required for unloading
