CorGal WST3902 – 64,900 Gallon Steel Water Tank
🛠️ Product Overview
The WST3902 is a large-diameter, low-profile corrugated steel water tank engineered for high-capacity water storage. With a 39′ footprint and a full-load capacity of over 548,000 lbs, it’s ideal for stormwater retention, fire protection reserves, and agricultural irrigation. Its galvanized construction, flat-packing for freight, and quick on-site assembly make it a preferred solution for large-scale above-ground storage.
Product Details
📏 Key Specifications
Model: WST3902
Capacity: 64,900 gallons
Diameter: 39′ 0″
Eave Height: 7′ 3″
Peak Height: 18′ 8″
Full Load Weight: ~548,000 lbs
Material: Corrugated galvanized steel
Use Cases: Stormwater, fire protection, irrigation, rainwater harvesting
Design: Above-ground with low eave for quick fill/discharge access
🚚 Shipping & Handling
Packaging: Flat-packed for cost-effective shipping
Shipping Method: Freight
Lead Time: 6–8 weeks typical
Installation Time: 4–6 days with certified crew
Site Prep: Level compacted pad or concrete ring beam
Tools Required: Forklift or crane for unloading
